Main features

Details
* Talk Distance limitless if network coverage
4G-F8 is an LTE/GSM/WCDMA radio which use data flow for communicate, with data covered area, users can talk freely.
* Unlimited Groups/Friends/Members
4G-F8 adopt RealPTT platform, Dealer management platform can create numerous groups, users, add users to same group to talk and set their right, level.
(p.s.: users id cost yearly fee)
* Single Call/Group Call/All Call
Users can choose another users to talk or call their group , or call some of the users from recently group
(User rights need to be set in the dealer management platform ).
* Adopt Realptt platform, free PC dispatcher
4G-F8 use REALPTT platform, users can login PC dispatcher to make call, monitor users, remote kill/stun,active, send message.
* Radio/Smart phone/ PC linked system
Users can download RealPTT apk to mobile phone and login in computer and write account to radio to make call or monitor.
(1 Realptt ID can login in only 1 terminal at the same time)
* GPS Location/ trajectory
Built in GPS function, on mobile phone or computer can watching users Real time GPS positioning and trajectory playback.
* Call Recorders
The content of the call and message is kept in the server, and it is deleted regularly.
* Dispatch Monitor/Call/SMS
users can login PC dispatcher to make call, monitor users, remote kill/stun,active, send message.
* Time-out-Timer
Timeout prohibition can set by PC program,preventing channel from being occupied
* PC programmable
Users have to program ID in to radio to start use
* Program password protect
Users can set password for program
* Remote Upgrade
Upgrade software for users self upgrade to latest version
* SOS function
SOS alarm for emergency circumstances
* Programmable side key
Users can define the side key function by software program according to their needs.




4G LTE Band specification

Version: SIM7600SA-H

Country/Area:New Zealand/Australia/South America

FDD-LTE:B1/2/3/4/5/7/8/28

TDD-LTE:B40

WCDMA:B1/2/5/8

GSM:850/900/1800/1900MHz


Version: SIM7600E-H

Country/Area: Europe/Middle East/Africa/South Korea/Thailand


FDD-LTE:B1/3/5/7/8/20

TDD-LTE:B38/40/41

WCDMA:B1/5/8

GSM:900/1800MHz

Version: SIM7600A-H

Country: USA(AT&T)

FDD-LTE:B2/B4/B12

WCDMA:B2/B5

Version: SIM7600X-H

Country: USA(Verizon Card)

FDD-LTE:B2/B4/B5/B13


General specification
Battery capability
4000mAh standard
Operate voltage
DC3.7V
Talk Platform
REALPTT
SIM Type
Standard sim card
Operate temperature
-20°C~~ +50°
Weight
194g
Dimension
98*58*35mm
Performance parameters

Receive type
56-Channel U-blox 7 engine
GPS/QZSS L1 C/A, GLONASS L1 FDMA
SBAS, WAAS, EGNOS,MSAS
Transmit power
GSM/GPRS power class: EGSM900: 4 (2W) DCS1800: 1 (1W)
EDGE power class: EGSM 900: E2 (0.5W) DCS1800: E1 (0.4W)
CDMA 1X power class:3 (0.25W)
UMTS power class: WCDMA :3 (0.25W) EVDO: 3 (0.25W)
Audio Output Power
Distortion <10%
Receiving sensitivity
-106dBm
Max transmit power
23-26dBm
GPS
Built in
